$328.00
HIK DS-7708NI-Q4 8-ch 1.5U 4K NVR—
$328.00
The Story
8-ch 1.5U 4K NVR
- Up to 8 channel IP cameras can be connected
- Supports decoding H.265+/H.265/H.264+/H.264 video formats
- Up to 4K high-definition live view, storage and playback
- Up to 4-ch @ 1080p decoding capacity
- Up to 80 Mbps high incoming bandwidth ensures IP cameras can be connected
- 1 HDMI and 1 VGA interfaces: both interfaces support independent video output
- 4 HDDs for continuous video recording
Available models:
DS-7708NI-Q4
Product Data
- Video and Audio
- IP Video Input8-ch
- HDMI Output1-ch, 4K (3840 × 2160)/30Hz, ,1920 × 1080p/60Hz, ,1600 × 1200/60Hz, ,1280 × 1024/60Hz, ,1280 × 720/60Hz, ,1024 × 768/60Hz; ,
- VGA Output1-ch, 1920 × 1080/60Hz, ,1280 × 1024/60Hz, ,1280 × 720/60Hz, ,1024 × 768/60Hz; ,
- Incoming Bandwidth80 Mbps
- Audio Output1-ch, RCA (Linear, 1 KΩ)
- Two-Way Audio1-ch, RCA (2.0 Vp-p, 1 k Ω)
- Decoding
- Decoding FormatH.265/H.265+/H.264/H.264+/MPEG4
- Decoding Capability1-ch @ 8 MP (30 fps) / 4-ch @ 1080p (30 fps)
- Synchronous playback8-ch
- Recording Resolution8 MP/6 MP/5 MP/4 MP/3 MP/1080p/UXGA/720p/VGA/4CIF/DCIF/ 2CIF/CIF/QCIF
- Network
- Network ProtocolTCP/IP, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, SMTP, NFS, iSCSI, UPnP?, HTTPS
- Network Interface2, RJ-45 10/100/1000 Mbps self-adaptive Ethernet interface
- PoE
- InterfaceN/A
- RAID
- RAID TypeNo
- Auxiliary Interface
- SATA4
- CapacityUp to 6 TB capacity for each disk
- Serial Interface1 RS-485 (half-duplex), 1 RS-232
- USB InterfaceFront panel: 2 × USB 2.0; Rear panel: 1 × USB 2.0
- Alarm In/Out16/4 (16/8 optional)
- General
- Power Supply100 to 240 VAC,â‿80 W
- Consumptionâ‿15 W
- Working Temperature-10 °C to 55 °C (14 °F to 131 °F)
- Working Humidity10 % to 90 %
- Dimension (W × D × H)440 × 393 × 75 mm (17.3" × 15.5" × 3.0")
- â‿5 kg (11 lb)
- IP Video Input8-ch
- HDMI Output1-ch, 4K (3840 × 2160)/30Hz, ,1920 × 1080p/60Hz, ,1600 × 1200/60Hz, ,1280 × 1024/60Hz, ,1280 × 720/60Hz, ,1024 × 768/60Hz; ,
- VGA Output1-ch, 1920 × 1080/60Hz, ,1280 × 1024/60Hz, ,1280 × 720/60Hz, ,1024 × 768/60Hz; ,
- Incoming Bandwidth80 Mbps
- Audio Output1-ch, RCA (Linear, 1 KΩ)
- Two-Way Audio1-ch, RCA (2.0 Vp-p, 1 k Ω)
- Decoding FormatH.265/H.265+/H.264/H.264+/MPEG4
- Decoding Capability1-ch @ 8 MP (30 fps) / 4-ch @ 1080p (30 fps)
- Synchronous playback8-ch
- Recording Resolution8 MP/6 MP/5 MP/4 MP/3 MP/1080p/UXGA/720p/VGA/4CIF/DCIF/ 2CIF/CIF/QCIF
- Network ProtocolTCP/IP, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, SMTP, NFS, iSCSI, UPnP?, HTTPS
- Network Interface2, RJ-45 10/100/1000 Mbps self-adaptive Ethernet interface
- InterfaceN/A
- RAID TypeNo
- SATA4
- CapacityUp to 6 TB capacity for each disk
- Serial Interface1 RS-485 (half-duplex), 1 RS-232
- USB InterfaceFront panel: 2 × USB 2.0; Rear panel: 1 × USB 2.0
- Alarm In/Out16/4 (16/8 optional)
- Power Supply100 to 240 VAC,â‿80 W
- Consumptionâ‿15 W
- Working Temperature-10 °C to 55 °C (14 °F to 131 °F)
- Working Humidity10 % to 90 %
- Dimension (W × D × H)440 × 393 × 75 mm (17.3" × 15.5" × 3.0")
- â‿5 kg (11 lb)
Description
8-ch 1.5U 4K NVR
- Up to 8 channel IP cameras can be connected
- Supports decoding H.265+/H.265/H.264+/H.264 video formats
- Up to 4K high-definition live view, storage and playback
- Up to 4-ch @ 1080p decoding capacity
- Up to 80 Mbps high incoming bandwidth ensures IP cameras can be connected
- 1 HDMI and 1 VGA interfaces: both interfaces support independent video output
- 4 HDDs for continuous video recording
Available models:
DS-7708NI-Q4
Product Data
- Video and Audio
- IP Video Input8-ch
- HDMI Output1-ch, 4K (3840 × 2160)/30Hz, ,1920 × 1080p/60Hz, ,1600 × 1200/60Hz, ,1280 × 1024/60Hz, ,1280 × 720/60Hz, ,1024 × 768/60Hz; ,
- VGA Output1-ch, 1920 × 1080/60Hz, ,1280 × 1024/60Hz, ,1280 × 720/60Hz, ,1024 × 768/60Hz; ,
- Incoming Bandwidth80 Mbps
- Audio Output1-ch, RCA (Linear, 1 KΩ)
- Two-Way Audio1-ch, RCA (2.0 Vp-p, 1 k Ω)
- Decoding
- Decoding FormatH.265/H.265+/H.264/H.264+/MPEG4
- Decoding Capability1-ch @ 8 MP (30 fps) / 4-ch @ 1080p (30 fps)
- Synchronous playback8-ch
- Recording Resolution8 MP/6 MP/5 MP/4 MP/3 MP/1080p/UXGA/720p/VGA/4CIF/DCIF/ 2CIF/CIF/QCIF
- Network
- Network ProtocolTCP/IP, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, SMTP, NFS, iSCSI, UPnP?, HTTPS
- Network Interface2, RJ-45 10/100/1000 Mbps self-adaptive Ethernet interface
- PoE
- InterfaceN/A
- RAID
- RAID TypeNo
- Auxiliary Interface
- SATA4
- CapacityUp to 6 TB capacity for each disk
- Serial Interface1 RS-485 (half-duplex), 1 RS-232
- USB InterfaceFront panel: 2 × USB 2.0; Rear panel: 1 × USB 2.0
- Alarm In/Out16/4 (16/8 optional)
- General
- Power Supply100 to 240 VAC,â‿80 W
- Consumptionâ‿15 W
- Working Temperature-10 °C to 55 °C (14 °F to 131 °F)
- Working Humidity10 % to 90 %
- Dimension (W × D × H)440 × 393 × 75 mm (17.3" × 15.5" × 3.0")
- â‿5 kg (11 lb)
- IP Video Input8-ch
- HDMI Output1-ch, 4K (3840 × 2160)/30Hz, ,1920 × 1080p/60Hz, ,1600 × 1200/60Hz, ,1280 × 1024/60Hz, ,1280 × 720/60Hz, ,1024 × 768/60Hz; ,
- VGA Output1-ch, 1920 × 1080/60Hz, ,1280 × 1024/60Hz, ,1280 × 720/60Hz, ,1024 × 768/60Hz; ,
- Incoming Bandwidth80 Mbps
- Audio Output1-ch, RCA (Linear, 1 KΩ)
- Two-Way Audio1-ch, RCA (2.0 Vp-p, 1 k Ω)
- Decoding FormatH.265/H.265+/H.264/H.264+/MPEG4
- Decoding Capability1-ch @ 8 MP (30 fps) / 4-ch @ 1080p (30 fps)
- Synchronous playback8-ch
- Recording Resolution8 MP/6 MP/5 MP/4 MP/3 MP/1080p/UXGA/720p/VGA/4CIF/DCIF/ 2CIF/CIF/QCIF
- Network ProtocolTCP/IP, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, SMTP, NFS, iSCSI, UPnP?, HTTPS
- Network Interface2, RJ-45 10/100/1000 Mbps self-adaptive Ethernet interface
- InterfaceN/A
- RAID TypeNo
- SATA4
- CapacityUp to 6 TB capacity for each disk
- Serial Interface1 RS-485 (half-duplex), 1 RS-232
- USB InterfaceFront panel: 2 × USB 2.0; Rear panel: 1 × USB 2.0
- Alarm In/Out16/4 (16/8 optional)
- Power Supply100 to 240 VAC,â‿80 W
- Consumptionâ‿15 W
- Working Temperature-10 °C to 55 °C (14 °F to 131 °F)
- Working Humidity10 % to 90 %
- Dimension (W × D × H)440 × 393 × 75 mm (17.3" × 15.5" × 3.0")
- â‿5 kg (11 lb)
