HIK DS-D4429RI-CBF P2.9 Indoor Rental LED display—
$1,000,000.00
The Story
P2.9 Indoor Rental LED display
- Cabinet is die-casting aluminum integrated.
- Modularized design: LED cabinet consists of frame, power box and modules. For different pixel pitches, they can share same power box and frame.
- Seamless connection: There are four locks totally on each cabinet. They can lock cabinets well for seamless splicing.
- One end of the power cables between two cabinets is fixed. Such design can help to realize fast installation and disassembly.
- Labor saving: One single person can manage installation easily, which can save labor cost.
- Screen can be both inward and outward curve.(optional)
- 90° connection is available(needs customization)
- Anti-collision design: there are protectors at the four corners of the cabinets, which can help to protect lamps effectively during transportation.(needs customization)
- Multi-application scenarios: It is widely used in concerts, events, opera houses, theaters, hotels, auditorium, multi-function hall, lecture hall, high-end entertainment venues, and so forth.
Available models:
DS-D4429RI-CBF
Product Data
- Cabinet
- Pixel ConfigurationSMD 3-in-1
- Pixel Pitch CategoryP2.97
- Pixel Pitch2.97 mm
- Modules Component2 × 2
-
Dimensions (W × H × D)
500（H）ÿ500（W）ÿ53（D）mm (19.685’‿×19.685’’ÿ.087’‿（not including modules＿/p>
500（H）ÿ500（W）ÿ70.6（D＿mm (19.685’’ÿ9.685’’ÿ.78’‿（including modules＿/p>
- Resolution168 × 168
- Area0.25 m?
- 6.8 Kg (14.99 lb)
- Pixel Density112896 dots/m?
- Lamp Board HousingNo housing
- Cabinet MaterialDie-casting aluminum
- Maintenance MethodFront and rear maintenance
- Cabinet Flatness0.1 mm
- Protection LevelFront protection level IP40
- Display
- White Balance Brightness≿00 cd/m?
- Color Temperature6500 K to 10000 K adjustable
- Viewing AngleHorizontal 160°, vertical 140°
- Contrast Ratio≿3000:1
- Color Uniformity≿± 0.003Cx，Cy
- Brightness Uniformity≿97＿/span>
- Processing Performance
- Driving MethodConstant current driving
- Frame Frequency60 Hz
- Refresh RateUp to 3840 Hz
- Grey LevelUp to 16 bit
- Display Color281 trillion
- Power
- Power Supply110V/220V
- Max. Consumption≿600 W/m?
- Average Consumption≿00 W/m?
- Working Environment
- Working Temperature-10-40 ℿ/span>
- Working Humidity10%~80%RH
- Storage Humidity10%~85%RH
- Storage Temperature-20~60 ℿ/span>
- General
- Gross Weight90 Kg (198.42 lb)±10%
- Package Dimensions (W × H × D)840（L）ÿ700（W）ÿ570（H＿mm (33.07" × 27.56" ×22.44" ) ＿-in-1 flight case＿/span>
- LifespanLamp 100,000 hours
- Pixel ConfigurationSMD 3-in-1
- Pixel Pitch CategoryP2.97
- Pixel Pitch2.97 mm
- Modules Component2 × 2
-
Dimensions (W × H × D)
500（H）ÿ500（W）ÿ53（D）mm (19.685’‿×19.685’’ÿ.087’‿（not including modules＿/p>
500（H）ÿ500（W）ÿ70.6（D＿mm (19.685’’ÿ9.685’’ÿ.78’‿（including modules＿/p>
- Resolution168 × 168
- Area0.25 m?
- 6.8 Kg (14.99 lb)
- Pixel Density112896 dots/m?
- Lamp Board HousingNo housing
- Cabinet MaterialDie-casting aluminum
- Maintenance MethodFront and rear maintenance
- Cabinet Flatness0.1 mm
- Protection LevelFront protection level IP40
- White Balance Brightness≿00 cd/m?
- Color Temperature6500 K to 10000 K adjustable
- Viewing AngleHorizontal 160°, vertical 140°
- Contrast Ratio≿3000:1
- Color Uniformity≿± 0.003Cx，Cy
- Brightness Uniformity≿97＿/span>
- Driving MethodConstant current driving
- Frame Frequency60 Hz
- Refresh RateUp to 3840 Hz
- Grey LevelUp to 16 bit
- Display Color281 trillion
- Power Supply110V/220V
- Max. Consumption≿600 W/m?
- Average Consumption≿00 W/m?
- Working Temperature-10-40 ℿ/span>
- Working Humidity10%~80%RH
- Storage Humidity10%~85%RH
- Storage Temperature-20~60 ℿ/span>
- Gross Weight90 Kg (198.42 lb)±10%
- Package Dimensions (W × H × D)840（L）ÿ700（W）ÿ570（H＿mm (33.07" × 27.56" ×22.44" ) ＿-in-1 flight case＿/span>
- LifespanLamp 100,000 hours
Description
P2.9 Indoor Rental LED display
- Cabinet is die-casting aluminum integrated.
- Modularized design: LED cabinet consists of frame, power box and modules. For different pixel pitches, they can share same power box and frame.
- Seamless connection: There are four locks totally on each cabinet. They can lock cabinets well for seamless splicing.
- One end of the power cables between two cabinets is fixed. Such design can help to realize fast installation and disassembly.
- Labor saving: One single person can manage installation easily, which can save labor cost.
- Screen can be both inward and outward curve.(optional)
- 90° connection is available(needs customization)
- Anti-collision design: there are protectors at the four corners of the cabinets, which can help to protect lamps effectively during transportation.(needs customization)
- Multi-application scenarios: It is widely used in concerts, events, opera houses, theaters, hotels, auditorium, multi-function hall, lecture hall, high-end entertainment venues, and so forth.
Available models:
DS-D4429RI-CBF
Product Data
- Cabinet
- Pixel ConfigurationSMD 3-in-1
- Pixel Pitch CategoryP2.97
- Pixel Pitch2.97 mm
- Modules Component2 × 2
-
Dimensions (W × H × D)
500（H）ÿ500（W）ÿ53（D）mm (19.685’‿×19.685’’ÿ.087’‿（not including modules＿/p>
500（H）ÿ500（W）ÿ70.6（D＿mm (19.685’’ÿ9.685’’ÿ.78’‿（including modules＿/p>
- Resolution168 × 168
- Area0.25 m?
- 6.8 Kg (14.99 lb)
- Pixel Density112896 dots/m?
- Lamp Board HousingNo housing
- Cabinet MaterialDie-casting aluminum
- Maintenance MethodFront and rear maintenance
- Cabinet Flatness0.1 mm
- Protection LevelFront protection level IP40
- Display
- White Balance Brightness≿00 cd/m?
- Color Temperature6500 K to 10000 K adjustable
- Viewing AngleHorizontal 160°, vertical 140°
- Contrast Ratio≿3000:1
- Color Uniformity≿± 0.003Cx，Cy
- Brightness Uniformity≿97＿/span>
- Processing Performance
- Driving MethodConstant current driving
- Frame Frequency60 Hz
- Refresh RateUp to 3840 Hz
- Grey LevelUp to 16 bit
- Display Color281 trillion
- Power
- Power Supply110V/220V
- Max. Consumption≿600 W/m?
- Average Consumption≿00 W/m?
- Working Environment
- Working Temperature-10-40 ℿ/span>
- Working Humidity10%~80%RH
- Storage Humidity10%~85%RH
- Storage Temperature-20~60 ℿ/span>
- General
- Gross Weight90 Kg (198.42 lb)±10%
- Package Dimensions (W × H × D)840（L）ÿ700（W）ÿ570（H＿mm (33.07" × 27.56" ×22.44" ) ＿-in-1 flight case＿/span>
- LifespanLamp 100,000 hours
- Pixel ConfigurationSMD 3-in-1
- Pixel Pitch CategoryP2.97
- Pixel Pitch2.97 mm
- Modules Component2 × 2
-
Dimensions (W × H × D)
500（H）ÿ500（W）ÿ53（D）mm (19.685’‿×19.685’’ÿ.087’‿（not including modules＿/p>
500（H）ÿ500（W）ÿ70.6（D＿mm (19.685’’ÿ9.685’’ÿ.78’‿（including modules＿/p>
- Resolution168 × 168
- Area0.25 m?
- 6.8 Kg (14.99 lb)
- Pixel Density112896 dots/m?
- Lamp Board HousingNo housing
- Cabinet MaterialDie-casting aluminum
- Maintenance MethodFront and rear maintenance
- Cabinet Flatness0.1 mm
- Protection LevelFront protection level IP40
- White Balance Brightness≿00 cd/m?
- Color Temperature6500 K to 10000 K adjustable
- Viewing AngleHorizontal 160°, vertical 140°
- Contrast Ratio≿3000:1
- Color Uniformity≿± 0.003Cx，Cy
- Brightness Uniformity≿97＿/span>
- Driving MethodConstant current driving
- Frame Frequency60 Hz
- Refresh RateUp to 3840 Hz
- Grey LevelUp to 16 bit
- Display Color281 trillion
- Power Supply110V/220V
- Max. Consumption≿600 W/m?
- Average Consumption≿00 W/m?
- Working Temperature-10-40 ℿ/span>
- Working Humidity10%~80%RH
- Storage Humidity10%~85%RH
- Storage Temperature-20~60 ℿ/span>
- Gross Weight90 Kg (198.42 lb)±10%
- Package Dimensions (W × H × D)840（L）ÿ700（W）ÿ570（H＿mm (33.07" × 27.56" ×22.44" ) ＿-in-1 flight case＿/span>
- LifespanLamp 100,000 hours
